Posted by Jim Earman ● Tue, Feb 08, 2011 @ 07:28 AM

Stain Marking Titanium with a 50 Watt Fiber Laser

Industry: Fabricated Metal

Part Type: Equipment Door

Material: Titanium 6AL4V

Mark Data Type: Text + Logo

Laser Mark Type: Multiple pass laser stain mark

laser marking titanium, laser etching titanium, stain marking titanium, fiber laser marking titanium, fiber laser engraving titanium, fiber laser system

The parts were marked using a Jimani Langolier Class IV open table 50 Watt fiber laser.

The above part size is 12” X 12” and the multiple pass stain mark was made using 420 mm lens (12” X 12” marking field).

laser marking titanium, laser marking titanium, laser etching titanium, laser engraving titanium, annealed laser mark, fiber laser, fiber laser system

A Jimani Langolier Fiber Laser Marking System is a turn key system and an amazingly versatile tool. The workstation's long Z Axis adjustment can place the focusing lens as high as 29 inches above the marking surface. The system easily accomodates long focal length lenses, parts fixtures and large or tall parts. The industry standard 19" rack mount computer and Langolier Fiber Laser Controller are housed in the workstation frame making the unit completely self contained with the exception of a single 115 VAC household outlet. Mounted on casters, the system, if need be, can be moved from one work area to another without being "tethered" by water or high voltage connections. All Langolier fiber laser marking systems are supplied with Prolase, a user friendly, proven, robust laser marking systems software package.

Topics: text, logo, open table, stain marking, titanium, 50 watt fiber
